Duplex Webbing Slings

Duplex Webbing Slings Duplex Webbing Slings Duplex Webbing Slings

Duplex Webbing Slings

Duplex Slings are manufactured from double layers of webbing. All of our polyester webbing sling products conform to EN standards and are delivered complete with certificates of conformity. Duplex Webbing Slings are lightweight and are less likely to scratch or damage the load being lifted. They resist mildew and bacterial growth and have excellent elongation properties in comparison to their nylon counterparts.

Features of Duplex webbing Slings

  • Safety factor 7:1 and 5:1
  • Available 12Ton from stock in most standard lengths
  • Color coded for easy identification
  • Custom made lifting solutions for non-standard applications
  • Available with a choice of wear sleeves for added protection at the load points
  • Hardware end fittings optional
  • Manufactured as standard in accordance to EN 1492-1:2000 or ASME B 30.9
Duplex Webbing Slings

  • 100% High Tenacity Polyester.
  • Made of Double thickness of Webbing.
  • Flat & Wide Load Bearing surface.
  • According to EN 1492-1:2000 or ASME B 30.9, Safety Factor 7:1 and 5:1.
  • Low Stretch Factor : Elongation 3-7%.
  • High strength to weight ratio : Weight 80% less than Equivalent Wire or Chain Slings.
  • Available upto 600 mm width & 12 Ton Capacity.
  • Colour coded for easy identification.
  • Maximum working temperature 90°c.
  • Anti-abrasion sleeves and anti-cutting sleeves protection (optional).
